144W 180W single Color/color changing RGB/

Description

1440W/180W AC100-250V single light color LED Floodlight,

288W DC24V DMX512 RGBW LED Floodlight,

with 144 pieces CREE/OSRAM/PHLIPS SMD LEDs,

With Meanwell / Philips Driver



Product Features:
1. Use fluid mechanics design, have a perfect combination of esthetic appearance and product functions. The lamp body is exquisite and beautiful. Fully structural waterproof design without glue, protection class IP66.
2. Use profile aviation aluminum Lamp body and 304 stainless steel screws. The bracket is equipped with dial holder and has gear lock function.
3. The surface uses outdoor level electrostatic spraying. It is corrosion resistance and suitable for harsh outdoor environments.
4. CREE/OSRAM/Philips LED light source optional, with excellent light color performance. High transmittance optical device, effectively improve the light output efficiency of the lamp. Anti-glare hood optional .
5. Single light color/DMX 3in1 RGB /DMX 4in1 RGBW  optional.
6. With Meanwell / Philips Driver, has good electromagnetic compatibility, no electromagnetic interference on the surrounding environment.



Specification:

Input Voltage: AC100-250V 50HZ / DC24V

Electrical safety class: Ι / Ш

LED light source: CREE / Osram / Philips

Driver: Meanwell / Philips

Control way: single color Constant currant / RGB/RGBW color changing DMX512

Beam Angle: 5 / 10/ 15 / 25 / 30 / 45 / 60 °

Weight: 8.50 KG

Lamp Size: L444*W70*H262 mm



---



Installation:

1. Loose thehexagon screws, adjust the bracket90 degrees forward and backward. After adjustment, fix the screw.
2. Fix the mounting holes on the bracket to the mounting place with screws.


   ---

Lamp Size:



Connection/Wiring of the lamps:

---
